- Support 16x10/100/1000Base-TX PoE ports, RJ45.
- Support 2x1000Base-FX SFP uplink ports.
- Support IEEE802.3af/at POE standards, maximum 30W output each port.
- Support 10/100/1000Base-T auto-sensed, Full/half duplex auto-sensed.
- 56G switching capacity, high bandwidth for data transmission.
- Support one key VLAN mode/Extra transmission mode, meeting different requirements.
- Support AC100~240V 50/60Hz wide power input.
- Reliable design of built-in power mode, up to 300W power output totally.
- Anti lightning and surge protection.
- Compact casing design, plug and play, easy maintenance.
|
| Interfaces |
Client Interface: 16x10/100/1000Base-T PoE ports, RJ45
Uplink Interface: 2x1000Base-Fx SFP slots |
| Switching |
Capacity: 56G
MAC address table: 8K
Support store-and-forward transmission |
| Standards |
IEEE802.3, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX/FX, IEEE 802.3ab 1000BASE-T,
IEEE 802.3z 1000BASE-X, IEEE802.3x Flow Control, IEEE802.1q VLAN,
IEEE802.3af PoE, IEEE802.3at PoE+ |
| Transmission Distance |
Cat5/5e/6: 100m |
| PoE |
16 ports active PoE, 1/2(+), 3/6(-)
DC48V, maximum 30W output each port |
| Power |
AC100~240V 50/60Hz input, total 300W power. |
| Indicators |
Power, V: enable VLAN mode; POE status, TX ports LINK/ACT status, SFP port LINK/ACT status. |
| Environmental Specification |
Working temperature: -10~55℃
Storage Temperature: -40 ° ~ 70 °C,
Working Humidity: 10% ~ 90%, no condensation
Storage Humidity: 5% ~ 90%, no condensation |
| Physical |
Mental Casing, 440x290x45mm (W*D*H)
Weight: 4200g |
|
